HRPO Sheets & Coils

HRPO SHEETS & COILS

HRPO or Hot Rolled Pickled and Oiled products and HRSPO or Hot-Rolled, Pickled, Skinpassed and Oiled products are low carbon steel goods available in the Hot-Rolled Flat products category. These are used mainly in instances where Flatness and Surface Finish are not the main criteria.

Features

  Durable
  High material strength
  Fine finish

Applications of HRPO products

• Automobiles
• Telecommunications
• Engineering and Fabrication
• Aerospace
• Furniture
• Drums and Barrels

Specifications & Grades

Grades

• IS 1079 HR1 - HR5; (JIS G 3131 SPHC, SPHD, SPHE)
• IS 10748 Grade1 - 5; (JIS G 3113 SAPH310, 370, 400 & 440)
• JIS G 3134 SPFH490, 540, 590, 540Y & 590Y
• IS 5986 Fe290, 330, 360, 410, 490 & 510

Thickness (T)

Width (W):

• Cut Sheets: 50 - 1600mm
• Coils: 40 - 1600mm
• Tolerance: +/- 0.50mm for Slit Edge, +12mm for Mill Edge

Coil Inner Dia:508 mm

Coil Weight (Max):16 MT for Slit Edge; 30 MT for Mill edge

Length (L):200 - 4000 (Tolerance: +1.00mm for L<=1000mm & +2.00mm for L>1000mm

Characteristics

• Good Surface Finish
• Flatness
• Weldability
• High Strength to Weight Ratio
• Close Dimensional Tolerances
